TRUCK-MOUNTED AERIAL PLATFORM

are range from 10 meters to 42 meters, which are ideal for all kinds of businesses. For instance, lamp post construction, building external wall cleaning, repair/installation of a canal, decorate an advertisement board and many more. They can also provide lighting and wide angle performance, excellent for commercial and movie filming.

TRUCK-MOUNTED AERIAL PLATFORM

 42M CTE

WORKING HEIGHT: 42meters
MAKE/MODEL: CTE
CAPACITY: 200kg/ 2 persons
BASKET SIZE(LxWxH): 1.5x1x1.1m

TRUCK WEIGHT: 30ton

TRUCK SIZE(LxWxH): 10.9x2.5x3.95m



FEATURE: The highest articulating truck-mounted aerial platform, Up-side down V level lift movement, rotatable basket. Ideal for external walls repair, glass curtain wall cleansing, etc.

 32M CTE

WORKING HEIGHT: 32meters
MAKE/MODEL: CTE
CAPACITY: 250kg/ 2 persons

BASKET SIZE(LxWxH): 2.4x0.8x1.1m

TRUCK WEIGHT: 16ton

TRUCK SIZE(LxWxH): 9.75x2.3x4.11m


FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

 32M TADANO(2)

WORKING HEIGHT: 32meters
MAKE/MODEL: TADANO | AT-300CG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.5x0.7x0.95m

TRUCK WEIGHT: 14ton

TRUCK SIZE(LxWxH): 9.43x2.3x3.7m


FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

 29.3M ITAMEC

 (2)

WORKING HEIGHT: 29.3meters
MAKE/MODEL: ITALMEC. ITALY
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 0.7x2.2x1.13m

TRUCK WEIGHT: 16ton

TRUCK SIZE(LxWxH): 9.32x2.49x3.9m


FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

 29M CTE

WORKING HEIGHT: 29meters
MAKE/MODEL: CTE | ZED 29J
CAPACITY: 230kg/ 2 persons

BASKET SIZE(LxWxH): 1.8x0.7x1.1m

TRUCK WEIGHT: 16ton

TRUCK SIZE(LxWxH): 10.28x2.47x3.5m

FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

 29M AICHI

WORKING HEIGHT: 29meters
MAKE/MODEL: AICHI
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.37x0.81x0.95m

TRUCK WEIGHT: 14ton

TRUCK SIZE(LxWxH): 8.86x2.44x4.04m

FEATURE: Telescopic. Ideal for external walls repair and glass curtain wall cleansing. Oscillating working platform.

 27.5 TADANO (3)

WORKING HEIGHT: 27.5meters
MAKE/MODEL: TADANO | AT-255CG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.2x0.7x0.95m

TRUCK WEIGHT: 10ton

TRUCK SIZE(LxWxH): 8.05x2.19x3.7m

FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc.

 22M TADANO

 (Super Deck)

WORKING HEIGHT: 22meters
MAKE/MODEL: TADANO | AT-200S
CAPACITY: 1000kg/ 2 persons

BASKET SIZE(LxWxH): 4.6x1.94x1.01m

TRUCK WEIGHT: 9ton

TRUCK SIZE(LxWxH): 7.44x2.26x3.81m


FEATURE: Extra large working platform. Ideal for external walls repair, glass curtain wall cleansing, and tunnel maintenance, etc. 360-degree continuous rotation basket.

 21.5M TADANO

 (2)

WORKING HEIGHT: 21.5meters
MAKE/MODEL: TADANO | AT-195CG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.2x0.7x0.95m

TRUCK WEIGHT: 10ton

TRUCK SIZE(LxWxH): 7.94x2.2x3.4m

FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc.

 21 SOCAGE

WORKING HEIGHT: 21meters
MAKE/MODEL: SOCAGE
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.83x0.8x0.99m

TRUCK WEIGHT: 10ton

TRUCK SIZE(LxWxH): 7.78x2.29x3.2m


FEATURE: Articulating. Ideal for external walls repair, glass curtain wall cleansing, and tunnel maintenance, etc. Oscillating working platform.

 18M TADANO

WORKING HEIGHT: 18meters

MAKE/MODEL: TADANO | AT-157CG

CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.2x0.7x0.95m

TRUCK WEIGHT: 9ton

TRUCK SIZE(LxWxH): 5.6x2.11x3.725m



FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

 18M TADANO

 (2)

WORKING HEIGHT: 18meters
MAKE/MODEL: TADANO | AT-155CG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.63x0.9x0.95m

TRUCK WEIGHT: 7.5ton

TRUCK SIZE(LxWxH): 6.15x2x3.2m


FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

 16M TADANO

WORKING HEIGHT: 16meters
MAKE/MODEL: TADANO | AT-155TG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.07x0.71x0.91m

TRUCK WEIGHT: 5.5ton

TRUCK SIZE(LxWxH): 5.8x2.18x3.66m


FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

 16M SIMON

WORKING HEIGHT: 16meters
MAKE/MODEL: SIMON
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1x0.6x1.11m

TRUCK WEIGHT: 5.5ton

TRUCK SIZE(LxWxH): 6.25x2.18x3.66m


FEATURE: Rotatable Basket. Ideal for hanging lamp post banner, construction and tunnel maintenance.

 14M TADANO

WORKING HEIGHT: 14meters
MAKE/MODEL: TADANO | AT-120TG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.12x0.77x0.94m

TRUCK WEIGHT: 9ton

TRUCK SIZE(LxWxH): 5.61x2.13x3.45m

FEATURE: Telescopic. Ideal for external walls repair, glass curtain wall cleansing and tunnel maintenance, etc. Oscillating working platform.

 14M TADANO (2)

 (Super Deck)

WORKING HEIGHT: 14meters
MAKE/MODEL: TADANO | AT-120S
CAPACITY: 1000kg/ 2 persons

BASKET SIZE(LxWxH): 2.5x1.55x1.02m

TRUCK WEIGHT: 9ton

TRUCK SIZE(LxWxH): 5.92x2.1x3.7m

FEATURE: Extra large working platform. Ideal for external walls repair, glass curtain wall cleansing and tunnel maintenance, etc. 360 degree continuous rotation basket.

 14M TADANO

WORKING HEIGHT: 14meters
MAKE/MODEL: TADANO | AT-120TG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 0.7x1x0.95m

TRUCK WEIGHT: 7.5ton

TRUCK SIZE(LxWxH): 5.42x2.13x2.85m


FEATURE: Tiny vehicle body, telescopic, oscillating working platform. Ideal for external walls repair, glass curtain wall cleansing, etc.

 12M TADANO

WORKING HEIGHT: 12meters
MAKE/MODEL: TADANO | AT-100TG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 0.7x1x0.9m

TRUCK WEIGHT: 5.3ton

TRUCK SIZE(LxWxH): 4.91x1.9x2.9m


FEATURE: Tiny vehicle body, telescopic, oscillating working platform. Ideal for external walls repair, glass curtain wall cleansing, etc.
